6–80 Meters • Portable Design • Up to 200W SSB
The Radioddity HF-008 is a compact, adjustable multi-band antenna designed for operators who want an easy-to-transport HF antenna for POTA, camping, field operations, emergency communications, and portable stations.
Covering frequencies from approximately 3.5–50 MHz, the HF-008 provides operation across multiple popular amateur bands from 80 meters through 6 meters. Its detachable design packs down to approximately 30.7 inches (78 cm), making it easy to transport with your portable radio equipment.
Pair it with a Xiegu G90 or other compatible HF transceiver for a compact portable station that can be set up without carrying a full-size wire antenna system.
3.5–50 MHz Frequency Coverage
80m through 6m Multi-Band Operation
Supports 80m, 40m, 30m, 20m, 17m, 15m, 10m, 11m and 6m
Up to 200W PEP on SSB
Up to 100W on CW
Adjustable telescopic antenna elements
Quick band changes using the supplied jumper cable
PL-259 / SL16-K 50Ω connection
Typical tuned SWR approximately 1.0–1.5
Copper and stainless-steel construction
Detachable design for easy transportation and storage
Packs down to approximately 30.7 inches
Approximately 22.9 oz. / 0.7 kg
2mm adjustment wrench included
The HF-008 is particularly well suited for operators who don't want to carry and deploy a large wire antenna every time they head into the field.
Instead of stringing wire through trees or setting up a large antenna system, the HF-008 can be installed on a suitable portable or magnetic antenna mount and adjusted for the desired operating band.
This makes it a great choice for:
Parks on the Air (POTA)
Portable HF operation
Camping and overlanding
Field Day
Emergency communications
Temporary base stations
Portable G90 stations
The HF-008 provides operating configurations for:
80 Meters – 3.56 MHz
40 Meters – 7.05 MHz
30 Meters – 10.1 MHz
20 Meters – 14 MHz
17 Meters – 18 MHz
15 Meters – 21.1 MHz
12/11/10 Meter Range – approximately 24.9–29 MHz
6 Meters – 50 MHz
Band selection is accomplished by changing the supplied jumper connection and adjusting the telescopic element to the appropriate length.
Fine adjustment of the whip allows the antenna to be tuned for your desired operating frequency.
When properly configured and installed, the HF-008 is designed to achieve approximately 1.0–1.5 SWR across its supported operating configurations.
For best results, adjust the antenna for the actual frequency you intend to use and verify SWR before transmitting.
A NanoVNA or antenna analyzer makes initial setup particularly easy. Once you determine the correct element lengths for your favorite frequencies, record those measurements for faster setups in the field.
The HF-008 makes an excellent portable antenna companion for the Xiegu G90 and the QMX+ Transceiver.
The G90's built-in SWR scanner and wide-range automatic antenna tuner complement the adjustable HF-008 and make it possible to assemble a capable portable HF station without carrying a large amount of equipment.
With the HF-008 rated for considerably more power than the G90 produces, operators also have room to use the antenna with higher-power HF equipment.
Radio, antenna mount, coax, and other station accessories are sold separately unless specifically stated otherwise.
Frequency Range: 3.5–50 MHz
Supported Bands: 80m / 40m / 30m / 20m / 17m / 15m / 10m / 11m / 6m
Nominal Impedance: 50Ω
Connector: PL-259 / SL16-K
Maximum Power: 200W PEP SSB / 100W CW
Typical Tuned SWR: 1.0–1.5
Construction: Copper and stainless steel
Storage Length: Approximately 78 cm / 30.7 in.
Weight: Approximately 0.7 kg / 22.9 oz.
Whip Adjustment: Telescopic with adjustable locking points
HF-008 antenna base with selectable jumper positions
Jumper cable
Fixed silver extension radial
Short adjustable top radial
Long adjustable top radial
2mm Allen wrench
Documentation
The HF-008 requires a suitable counterpoise or ground plane for proper operation.
The manufacturer recommends using the antenna with a suitable magnetic mount installed on a vehicle or another structure capable of providing an adequate counterpoise. It is not designed to simply screw directly onto the antenna connector of an HF transceiver.
For portable operation, always verify antenna SWR before transmitting and make final element-length adjustments for your installation and operating frequency.
The HF-008 is intended primarily as a stationary portable antenna. It should not be used on a vehicle while the vehicle is moving.
Avoid operating or storing the antenna in wet environments to help prevent corrosion.
Pair the Radioddity HF-008 with the Xiegu G90, a suitable antenna mount, and a portable battery to build a compact HF station that's easy to transport and quick to deploy at your next POTA activation, campsite, or field operating location.
