3D Printable USB-C Opening Drill Template for the TA7MNA QMX+ Internal Battery & Audio Board Kit
Make installing the TA7MNA Internal Battery & Audio Board Kit in your QRP Labs QMX+ easier with this custom-designed, 3D-printable USB-C drill template from CQ Homestead Supply.
This template is designed to help builders accurately locate and create the USB-C charging port opening when modifying their QMX+ enclosure for the TA7MNA Battery & Audio Board Kit.
Instead of measuring and marking the opening by hand, simply 3D print the template and use it as a guide when drilling and filing the USB-C opening.
Instant Digital Download – Receive an STL file ready for 3D printing.
Designed for the TA7MNA Battery & Audio Kit – Intended for builders installing the internal battery and audio upgrade in their QMX+.
Easy to 3D Print – Print your own reusable drill template.
Simplifies Enclosure Modification – Helps locate the USB-C opening and guide the modification process.
Reusable Design – Ideal for builders assembling multiple QMX+ radios or upgrade kits.
Download the STL file and 3D print the drill template.
Position rear lid on the self alignment posts and center puch your drill holes.
Use a 3 mm or 1/8-inch drill bit to drill each end of the USB-C opening.
Carefully remove the remaining material between the holes.
Use a small file to clean up and finish the opening.
Test-fit the USB-C connector before completing your installation.
Always verify template alignment and USB-C connector positioning before drilling or modifying your enclosure.
One digital STL file for the USB-C drill template.
This is a DIGITAL DOWNLOAD ONLY. No physical template, QMX+ radio, battery board, or other hardware is included.
This template is intended for use with the TA7MNA QMX+ Internal Battery & Audio Board Kit, which adds internal battery power, charging capabilities, battery management, and amplified speaker audio to the QRP Labs QMX+ transceiver.
The upgrade kit is available separately from CQ Homestead Supply:
TA7MNA QMX+ Internal Battery & Audio Board Kit
Requires access to a 3D printer.
Requires drilling and filing of the radio enclosure.
The builder is responsible for verifying fitment and completing all modifications.
This download does not include the TA7MNA electronics kit.
Digital files are intended for personal use. Commercial reproduction or resale requires permission from CQ Homestead Supply.
Designed and offered by CQ Homestead Supply LLC
